Technical Specifications
| Parameters | Features (typ.) |
|---|---|
| 4 GHz Phase Noise | ≤ -150 dBc/Hz at 100KHz offset |
| 8 GHz Phase Noise (Input Reference) | |
| 12 GHz Phase Noise | |
| 16 GHz Phase Noise | |
| 20 GHz Phase Noise | |
| 40 GHz Phase Noise | |
| Spurious Rejection | -60dBc from 10 MHz to 40 GHz |
| Output | >10dBm min. at all outputs |
| VSWR | 2:1 (typ.) |
| Weight | < 5 Kg (typ.) |
| Size | 25 x 25 x 5 cm (typ.) |
